Item |
Technical Parameter |
||
|
Accuracy |
0.02 Class |
0.05 Class |
|
|
? DC voltage ? DCU |
Range |
Expanded uncertainty（K=2） ? ±（ppm*RD+ppm*RG） |
|
|
1～1500V |
70+20 |
150+30 |
|
|
0.25～0.5V |
70+50 |
150+80 |
|
|
25mV～100mV |
70+50 |
200+80 |
|
|
DC Current DCI |
10mA～500A |
80+20 |
200+50 |
|
2.5mA～5mA |
150+20 |
250+50 |
|
|
DC Current Small signal DCIU |
25mV～10V |
80+15 |
150+25 |
|
2.5mV～10mV |
100+30 |
200+50 |
|
|
1mV |
100+0.3uV |
150+0.3uV |
|
|
Power supply |
AC220V±10%，50Hz；Max.power consumption：30VA |
||
|
Operating Temperature |
20℃-30℃ |
||
|
Humidity |
≤85%R.H |
||
|
Dimension(mm) |
485×400×135mm |
||
|
Weight |
8Kg |
||
Function Advantage:
DC high current measurement: the built-in broadband current comparator completes the I/V conversion and converts the current signal into a voltage signal, which is suitable for direct access DC energy meter verification device
Small signal voltage measurement: can directly measure the voltage signal, suitable for indirect access (shunt access) DC energy meter verification device.
Stability test: stability test time can be set, and visual display of stability value. Optional power, voltage, current stability test.
Statistical analysis of l data: calculate the maximum, minimum, average, standard deviation and so on.
DC ripple test: maximum 5 kHz of measurement bandwidth, uncertainty 0.1%
Power metering: with standard power pulse input / output interface, it can be used as the standard of high grade DC power metering.
Smart control: can access other computer systems to achieve automatic measurement.
HMI (Human-Machine Interaction): easy to operate, equipped with 7-inch capacitive screen, beautiful and generous display interface, rich and intuitive content.
-->
